Another piece of the puzzle: New study sheds light on oil’s effects on plant life

January 13, 2015 | Posted by Delta Dispatches in BP Oil Disaster, Science

By Matt Phillips, National Wildlife Federation

The 2010 BP Deepwater Horizon oil disaster spilled nearly 200 million gallons of oil into the Gulf of Mexico. Oil coated the shore, covering hundreds of miles of coastline, including some of Louisiana’s coastal wetlands. Scientists have spent the years since the spill assessing its continuing impacts on Gulf wildlife and ecosystems. And next Tuesday in New Orleans, Phase III of the BP oil spill trial will start in New Orleans.

In a recent study, “Physiological relationship between oil tolerance and flooding tolerance in marsh plants,” Keri L. Caudle and Brian R. Maricle of Fort Hays State University in Kansas studied how oil affects plant health. Studies have demonstrated that oil can poison plants, and toxic chemicals in oil can prevent photosynthesis – the process by which plants convert sunlight to food. Since all Gulf Coast wildlife, including birds, turtles, dolphins and insects, ultimately rely on plants for food and shelter, the effects of oil on plant life could impact the entire Gulf Coast ecosystem.

Switchgrass (Panicum virgatum) is a flooding-sensitive species.

Switchgrass (Panicum virgatum) is a flooding-sensitive species.

Besides a general toxic effect, relatively little is known about how oil impacts plant health. However, substantial research has assessed how plants deal with flooding. The authors of this study hypothesized that a plant’s response to flooding might be similar to its response to oil. In both situations, plants have a harder time absorbing oxygen from their surroundings. Oxygen is critical to a plant’s survival: Plants breathe similarly to humans at times, absorbing oxygen and exhaling carbon dioxide. If oil seeps into the soil, it could cover the plant’s roots, preventing them from absorbing oxygen.

The authors wanted to determine if oil harmed plants by preventing oxygen absorption or by poisoning them. To do so, they labeled nine species of plants as either flooding tolerant, moderately flooding tolerant or flooding sensitive. Because flooding prevents plants from absorbing oxygen from soil, flooding tolerance was an appropriate stand-in for oil tolerance. The researchers reasoned that if oil’s effects primarily prevented plants from getting oxygen, plants would have to breathe without taking in oxygen.

Prairie cordgrass (Spartina pectinata) is a moderately flooding-tolerant species.

Prairie cordgrass (Spartina pectinata) is a moderately flooding-tolerant species.

Plants are able to breathe without oxygen temporarily and produce a certain chemical compound in their roots when doing so. Therefore, the researchers measured whether this chemical was being produced to determine if the plants were still breathing but forgoing oxygen. If the effects of oil were instead due to toxic effects, then the plants would be less able to photosynthesize because their cells would be poisoned and unable to function properly.

The experimenters observed three important results. They found that flooding-sensitive plant species were breathing without oxygen, suggesting that they were struggling to absorb it from the soil. They also observed that flooding-tolerant species were not having trouble absorbing oxygen, suggesting that their tolerance to flooding afforded them a higher tolerance to oil. Third, they discovered that, regardless of tolerance to flooding, plants exposed to oil were photosynthesizing less than under normal conditions. The researchers determined that the toxic effects of the oil were interrupting the photosynthetic process.

Smooth cordgrass (Spartina alterniflora) is a flooding-tolerant plant species.

Smooth cordgrass (Spartina alterniflora) is a flooding-tolerant plant species.

The study concluded that oil affected plants most harmfully by preventing oxygen absorption, rather than through its toxic properties. Flooding-tolerant plants were better able to withstand the effects of oil, and continue absorbing oxygen, whereas flooding-sensitive plants had a harder time. They also recognized that across the board, oil proved toxic to plants. Oil tolerance followed flooding tolerance, but the toxic effects of the oil were still present across all species.

Plants are the foundation of the Gulf Coast ecosystem. Discovering the effects of oil on plant health is critical to understanding the full effects of the BP oil spill on Gulf Coast wildlife, as wildlife depend on plants for food and habitat. With this study, we have another piece of the puzzle.

Leave a comment

River diversion model debuted at Plaquemines Parish Orange Festival

January 9, 2015 | Posted by Delta Dispatches in Diversions, Hurricanes, Meetings/Events, Restoration Projects

By Philip Russo, Outreach Coordinator, Restore the Mississippi River Delta Coalition

Land along a river has long been coveted for its agricultural productivity, but few rivers can compete with the mighty Mississippi.

Philip Russo shows off with the Restore the Mississippi River Delta coalition's diversion model at the Plaquemines Orange Festival.

Philip with the Restore the Mississippi River Delta coalition's diversion model.

With a drainage basin stretching across 31 U.S. states and parts of Canada, it is no surprise that the Mississippi River carries a lot of sediment. Historically, the river would deposit this sediment near its mouth in what is now southeast Louisiana, creating new land. But since leveeing of the river, the majority of this sediment is lost out the mouth of the river and into the deep waters of the Gulf of Mexico.

Near the mouth of the Mississippi, the final 85-mile stretch of the Mississippi River in Plaquemines Parish is home to prodigious citrus farming land. And with cool temperatures and clear skies, the weather of early December was ripe for the 68th Annual Plaquemines Parish Orange Festival.

Plaquemines Orange Festival

Sunset at the Orange Festival

Nestled between the Mississippi River levee and historic Fort Jackson, the focus of the festival is all things citrus. In Louisiana, that means copious displays of red navels, tangelos, ruby red grapefruits, sweet oranges, satsumas, kumquats and more.

While we attended and blogged about our trip down to the Orange Festival last year, this was the first year we actively engaged the crowds about protecting and restoring our coast – and we got to do so while debuting our tabletop river delta model! Watch this short video of the diversion model in action.

There are some sections of Plaquemines Parish where the distance between the Mississippi River levee and the Barataria Bay levee is only a few hundred yards, so Plaquemines residents are familiar with and usually eager to talk about their coast. But having a model demonstrating the process which built the very land everyone is standing adds another dimension to conversations about restoring barrier islands, ridges and marsh.

Fort Jackson entrance to the festival.

Fort Jackson entrance to the festival.

This year’s Orange Festival celebrated yet another successful harvest, but the celebration – originally organized in 1947 to promote Plaquemines’ citrus crop – has known its setbacks, most significantly due to Hurricanes Betsy, Camille and Katrina. If we are going to ensure the success of future harvests, we need to restore our multiple lines of defense against storm surge and maintain our protective coastal wetlands with strategically located and operated diversions along the river.

Leave a comment

What can the Caernarvon Diversion and Bohemia Spillway teach us about coastal restoration?

December 23, 2014 | Posted by Elizabeth Van Cleve in Diversions, Reports, Restoration Projects, Science

By Theryn Henkel, Ph.D., Lake Pontchartrain Basin Foundation

The Coastal Sustainability Program at the Lake Pontchartrain Basin Foundation (LPBF) recently released an article titled “Examination of Deltaic Processes of Mississippi River Outlets–Caernarvon Delta and Bohemia Spillway in Southeastern Louisiana in the Gulf Coastal Association of Geological Societies Journal. The article details work that LPBF has done investigating the development of the Caernarvon Delta and operation of the Bohemia Spillway, both located in Plaquemines Parish, La.

Natural land-building deltaic processes of the Mississippi River Delta have been severely limited by artificial river levees, which prevent water and sediment from flowing over the banks during spring floods. To counteract the effects of severing the connection between the river and the delta, focus has been placed on reconnecting the river to the surrounding wetlands by the creation of artificial outlets, also called diversions.

The Caernarvon Diversion

The Caernarvon Freshwater Diversion was designed to deliver up to 8,000 cubic feet per second (cfs) of water from the Mississippi River. For reference, a flow rate of 8,000 cfs could fill up an Olympic-size swimming pool in 11 seconds or the Superdome in 4.5 hours. The Mississippi River also contains sediment that is carried along with the fresh water through the Caernarvon Diversion into the adjacent wetlands or open water, where it can nourish the wetlands and/or build land.

Record of Caernarvon Freshwater Diversion discharge and turbidity for 2012, as an example of the discrepancy between timing of diversion operations and sediment spikes entering the Caernarvon Receiving Basin. Also illustrated is the under- operation of the diversion during high stage events in the Mississippi River. The difference between the solid blue area and the hachured is the potential additional flow that was not allowed due to management of the diversion. The orange line is the turbidity of the discharge, which shows that the few times when the diversion was operated at higher flow it was often not when turbidity was elevated.

Record of Caernarvon Freshwater Diversion discharge and turbidity for 2012, as an example of the discrepancy between timing of diversion operations and sediment spikes entering the Caernarvon Receiving Basin.

LPBF collects data on the turbidity, or cloudiness, of the water diverted through the diversion. Through established equations, the cloudiness of the water can be related to sediment load or the amount of sediment carried in the water. From this, it was calculated that the total amount of sediment carried into the wetlands and open waters areas from 2009 to 2012 was 264,000 cubic yards, or a volume equal to 81 swimming pools. Due to other considerations, the diversion is not always operated when the sediment load in the river is high and therefore does not maximize potential sediment capture. Despite this variability in operation of the diversion – and the fact that the Caernarvon Diversion was built to minimize sediment capture, as it was built solely for salinity control, not land building – there actually has been enough sediment diverted by the Caernarvon Diversion to build a new delta. Total wetland growth of the delta in the open water area receiving diverted water from 1998 to 2011 was 600 acres. This new wetland area is lush and thriving with a variety of plant species (trees and herbaceous) growing, and alligators, birds and insects abound.

The Bohemia Spillway

The Bohemia Spillway is an 11-mile stretch along the east side of Mississippi River south of New Orleans where the federal protection levees were removed. It was created in 1926 by the removal of existing artificial river levees, thereby allowing river water to flow over the banks and into the adjacent wetlands when the river was high. This overflowing process is how the river would have operated historically.

Location of the Caernarvon Diversion and Bohemia Spillway in relation to New Orleans and other river outlets.

Location of the Caernarvon Diversion and Bohemia Spillway in relation to New Orleans and other river outlets.

In 2011, the Mississippi River watershed experienced an historic flood which provided an ideal opportunity to investigate and study how the spillway operates. When the river overflows its banks, if brings fresh water, nutrients and sediment to the wetlands. This cannot happen when the connection is cut off by levees. The severing of the connection of the river to the wetlands is one of the contributing factors to the high rates of land loss rates experienced by southeast Louisiana.

Current land loss rates in the Bohemia Spillway are negligible, perhaps due to receiving inputs of fresh water, nutrients and sediment during high river events since 1926. We have not observed delta formation in the Bohemia Spillway, as we did at the Caernarvon Diversion, but we have observed the infilling of defunct navigation and oil and gas canals as they slowly convert back to land.

In many parts of Louisiana’s coast, man-made canals often contribute to increased land loss. Poorly maintained canals erode and become wider, and salt water is conveyed through the canals into adjacent fresh marshes, killing plants and converting land to open water. Therefore, seeing canals infilling and low rates of land loss in the Bohemia Spillway indicates that the restoration of somewhat normal processes, by reconnecting the river to the wetlands since 1926, has had a positive effect on the area.

Looking Ahead

For both Bohemia Spillway and the Caernarvon Diversion, there are clearly benefits to sustaining or increasing wetland areas. However, the two outlets also provide a contrast in the future possibilities. Precisely replicating the Bohemia Spillway by levee removal is generally not feasible because of the ongoing need for protection from river floods. However, a controlled diversion built and operated to more efficiently capture and deliver sediment in ways that emulate more natural processes, such as in the Bohemia Spillway, may hold great promise for coastal restoration, rather than the obsolete design and operational goals of a diversion such as Caernarvon.
